Jimny 3-Door Specifications
JXN CARRY MANUAL
SIERRA MANUAL
SIERRA MANUAL TWO TONE
SIERRA AUTO
SIERRA AUTO TWO TONE
+
–
INFOTAINMENT
| SAT NAV | |||||
| Smartphone connected navigation | |||||
| AUDIO & MEDIA | |||||
| Touchscreen infotainment | |||||
| Tuner/MP3/WMA | |||||
| Two speaker system | |||||
| Bluetooth® handsfree connectivity | |||||
| Smartphone connectivity | |||||
| Apple CarPlay | |||||
| Android Auto™ | |||||
| USB input | |||||
+
–
INSTRUMENT PANEL
| INFO DISPLAY | |||||
| Digital clock | |||||
| Outside temperature | |||||
| Fuel display instantaneous/average/range | |||||
| Gear position indicator | |||||
| PANEL | |||||
| Tachometer | |||||
| Fuel warning indicator | |||||
| Lights-on and key reminder | |||||
| Door ajar warning indicator | |||||
| Seatbelt reminder for all seating positions | |||||
+
–
INTERIOR
| AIR-CONDITIONING | |||||
| Manual air conditioning with pollen filter | |||||
| Climate control air conditioning with pollen filter | |||||
| STEERING | |||||
| Urethane steering wheel with cruise, limiter, phone & audio controls | |||||
| Leather steering wheel with cruise, limiter, phone & audio controls | |||||
| Tilt adjustable steering wheel | |||||
| Power steering | |||||
| DRIVE TRAIN | |||||
| Part time 4WD with low transfer gear | |||||
| SEATING | |||||
| Walk-in mechanism on passenger’s side | |||||
| 50:50 split-folding rear seats | |||||
| Adjustable/detachable head restraints front | |||||
| Adjustable/detachable head restraints rear x 2 | |||||
| Assist grips x 3 | |||||
| UPHOLSTERY | |||||
| Cloth fabric | |||||
| CABIN LIGHTING | |||||
| 3 position lights on/off/door | |||||
| SUN VISOR & MIRRORS | |||||
| Sun visors | |||||
| Ticket holder driver's side | |||||
| Ticket holders both sides | |||||
| Vanity mirror driver's side | |||||
| Vanity mirrors both sides | |||||
| Day/night rearview mirror | |||||
| STORAGE | |||||
| Glovebox | |||||
| Front seatback pocket on passenger’s side | |||||
| Front door storage pockets | |||||
| Drink holders 2 rear | |||||
| LUGGAGE AREA | |||||
| Luggage area storage box | |||||
| Luggage area light | |||||
| POWER-OUTLET | |||||
| 12V accessory socket front | |||||
| 12V accessory socket front and rear | |||||
+
–
EXTERIOR
| SIDES | |||||
| Wheel arch extensions | |||||
| REAR | |||||
| External tailgate opener | |||||
| ROOF | |||||
| Two-tone | |||||
| Drip rails | |||||
| Removable rubber aerial | |||||
| HEADLAMPS | |||||
| Halogen multi-reflector | |||||
| LED projector | |||||
| Auto levelling | |||||
| Auto light-sensing | |||||
| Headlamp washers | |||||
| Daytime running lamps | |||||
| Guide Me light | |||||
| FOG LAMPS | |||||
| Front fog lamps | |||||
| WINDOWS | |||||
| Electric windows | |||||
| Privacy glass (rear passenger and hatch) | |||||
| MIRRORS | |||||
| Black mirrors and door handles | |||||
| Body-coloured mirrors and door handles | |||||
| Electrically adjustable exterior mirrors | |||||
| Electrically folding exterior mirrors | |||||
| WIPERS | |||||
| 2-speed with intermittent and washer | |||||
| Rear wiper and washer | |||||
| Rear window demister | |||||
| WHEELS | |||||
| 15 inch steel wheels | |||||
| 15 inch alloy wheels | |||||
| Full size spare with half cover | |||||
+
–
SAFETY & SECURITY
| ENTRY & START | |||||
| Remote central door locking with hazard answer-back | |||||
| SAFETY | |||||
| 5 year roadside assistance | |||||
| 5 year extensive warranty programme (see Suzuki Warranty page for details) | |||||
| Electronic Stability Programme (ESP®) | |||||
| Dual Sensor Brake Support | |||||
| Cruise control | |||||
| Speed limiter | |||||
| Lane departure warning | |||||
| Weaving alert | |||||
| Side impact beams | |||||
| Collapsible steering column | |||||
| Brake decoupling mechanism | |||||
| Brake and clutch decoupling mechanism | |||||
| BRAKES | |||||
| Anti-lock Braking System (ABS) | |||||
| Electronic Brakeforce Distribution (EBD) | |||||
| Brake assist | |||||
| Brake override system | |||||
| Hill hold control | |||||
| Hill descent control | |||||
| Shift lock and key interlock | |||||
| Brake LSD control | |||||
| AIRBAGS | |||||
| SRS dual front airbags | |||||
| Driver and passenger side airbags | |||||
| Front and rear curtain airbags | |||||
| SEATBELTS | |||||
| Front 3-point ELR with pretensioners and force limiters | |||||
| Rear 3-point ELR x 2 | |||||
| ISOFIX child seat anchorages x 2 | |||||
| LIGHTS | |||||
| High beam assist | |||||
| High mounted stop lamp | |||||
| SECURITY | |||||
| Engine immobiliser | |||||
+
–
DIMENSIONS
| Overall length (mm) | 3,480 | 3,480 | 3,480 | 3,480 | 3,480 |
| Overall width (mm) | 1,645 | 1,645 | 1,645 | 1,645 | 1,645 |
| Overall height (mm) | 1,720 | 1,720 | 1,720 | 1,720 | 1,720 |
| Wheelbase (mm) | 2,250 | 2,250 | 2,250 | 2,250 | 2,250 |
| Tread Front (mm) | 1,395 | 1,395 | 1,395 | 1,395 | 1,395 |
| Tread Rear (mm) | 1,405 | 1,405 | 1,405 | 1,405 | 1,405 |
| Ground clearance (mm) | 210 | 210 | 210 | 210 | 210 |
| Minimum turning radius (m) | 4.9 | 4.9 | 4.9 | 4.9 | 4.9 |
| Approach angle (deg) | 37 | 37 | 37 | 37 | 37 |
| Ramp breakover (deg) | 28 | 28 | 28 | 28 | 28 |
| Departure angle (deg) | 49 | 49 | 49 | 49 | 49 |
| Overall length incl. spare wheel | 3,645 | 3,645 | 3,645 | 3,645 | 3,645 |
+
–
WEIGHTS
| Kerb weight (min. kg) | 1,095 | 1,095 | 1,095 | 1,110 | 1,110 |
| Gross vehicle weight (kg) | 1,435 | 1,435 | 1,435 | 1,435 | 1,435 |
+
–
ENGINE
| Engine type | K15B | K15B | K15B | K15B | K15B |
| Number of cylinders | 4 | 4 | 4 | 4 | 4 |
| Number of valves | 16 | 16 | 16 | 16 | 16 |
| Piston displacement (cm3) | 1,462 | 1,462 | 1,462 | 1,462 | 1,462 |
| Bore x stroke (mm) | 74.0 x 85.0 | 74.0 x 85.0 | 74.0 x 85.0 | 74.0 x 85.0 | 74.0 x 85.0 |
| Compression ratio | 10:1 | 10:1 | 10:1 | 10:1 | 10:1 |
| Maximum output (kW@rpm) | 75/6,000 | 75/6,000 | 75/6,000 | 75/6,000 | 75/6,000 |
| Maximum torque (Nm@rpm) | 130/4,000 | 130/4,000 | 130/4,000 | 130/4,000 | 130/4,000 |
| Fuel distribution | Multipoint injection | Multipoint injection | Multipoint injection | Multipoint injection | Multipoint injection |
| Fuel type | 91RON or greater | 91RON or greater | 91RON or greater | 91RON or greater | 91RON or greater |
| C02 emissions NEDC (g/km) | 146 | 146 | 146 | 158 | 158 |
| C02 emissions 3P-WLTP conversion (g/km) | 162 | 162 | 162 | 176 | 176 |
| Fuel consumption NEDC (L/100 km) | 6.4 | 6.4 | 6.4 | 6.9 | 6.9 |
| Fuel consumption 3P-WLTP conversion (L/100 km) | 7.1 | 7.1 | 7.1 | 7.7 | 7.7 |
| Fuel consumption will vary due to factors such as vehicle condition, driving style and traffic conditions. |
+
–
TRANSMISSION
| Type | 5-speed manual | 5-speed manual | 5-speed manual | 4-stage auto | 4-stage auto |
| Drive system | ALLGRIP PRO 4WD | ALLGRIP PRO 4WD | ALLGRIP PRO 4WD | ALLGRIP PRO 4WD | ALLGRIP PRO 4WD |
| Gear ratio 1st | 4.42 | 4.42 | 4.42 | 2.88 | 2.88 |
| Gear ratio 2nd | 2.3 | 2.3 | 2.3 | 1.57 | 1.57 |
| Gear ratio 3rd | 1.67 | 1.67 | 1.67 | 1 | 1 |
| Gear ratio 4th | 1.19 | 1.19 | 1.19 | 0.7 | 0.7 |
| Gear ratio 5th | 1 | 1 | 1 | ||
| Reverse | 5.15 | 5.15 | 5.15 | 2.3 | 2.3 |
| Final gear ratio | 4.09 | 4.09 | 4.09 | 4.3 | 4.3 |
| Transfer gear ratio high | 1 | 1 | 1 | 1.32 | 1.32 |
| Transfer gear ratio low | 2. | 2. | 2. | 2.64 | 2.64 |
+
–
CHASSIS
| Steering | Recirculating ball | Recirculating ball | Recirculating ball | Recirculating ball | Recirculating ball |
| Brakes Front | Solid disc | Solid disc | Solid disc | Solid disc | Solid disc |
| Brakes Rear | Drum, leading and trailing | Drum, leading and trailing | Drum, leading and trailing | Drum, leading and trailing | Drum, leading and trailing |
| Suspension Front | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring |
| Suspension Rear | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring | 3-link rigid axle with coil spring |
| Tyres | 195/80R15 | 195/80R15 | 195/80R15 | 195/80R15 | 195/80R15 |
+
–
CAPACITIES
| Rear loadspace carrying capacity | 265 kg | ||||
| Luggage capacity Rear seats raised (Litres VDA method) | 85 | 85 | 85 | 85 | |
| Luggage capacity Rear seats folded (Litres VDA method) | 377 | 377 | 377 | 377 | |
| Fuel tank capacity (Litres) | 40 | 40 | 40 | 40 | 40 |
| Towing capacity unbraked (kg) | 500 | 500 | 500 | 500 | 500 |
| Towing capacity braked (kg) | 950 | 950 | 950 | 950 | 950 |
| Seating capacity (persons) | 2 | 4 | 4 | 4 | 4 |
